The Iron Line Series amps feature the most compact and enhanced design in the market, while offering high fidelity sound in bass, mid and highs.
TECHNICAL SPECIFICATIONS
Number of Channels: 4
RMS Power at 2 Ohm 13.8V: 4 x 100W RMS
RMS Power at 4 Ohm 13.8V: 4 x 60 W RMS
Power @ 13.8V Bridge 4 Ohms: 2 x 200W RMS
Supply Voltage: 9 ~ 15V
Frequency Response: 10Hz ~ 30 KHz
Crossover Low Pass: 90 Hz
Crossover High Pass: 90 Hz
Signal to Noise: > 90 dB
Harmonic Distortion: > 0,03 % THD
Input Sensitivity: 200 mV
Input Impedance: 20K Ohms
Impedance Output: 2 Ohms Stereo / 4 Ohms Bridge
Consumption with Musical Signal: 16 A
Consumption with Bass Signal: 32 A
Dimensions (H x W x D): 52 x 127,5 x 11
Weight: 1.2 lb / 0.6 kg
